Particle™ is a granular delay / pitch shifting pedal. It chops your signal into small grains and then rearranges, shifts, and mangles it, using the techniques of granular synthesis in real time. Results range from radical pitch and delay modulation to shimmering repeats to time stretching, stutter, and glitch sounds.

Five delay and three pitch modes give intuitive control over random delays, bubbling textures, time stretching, and rhythmic glitches. Take a unique approach beyond conventional delay, pitch, flanging, and chorus sounds. Freeze notes with adjustable threshold for stutter, punch in, or drone-line effects. Lock multiple parameters to tap tempo or MIDI sync with independent note divisions for intricate rhythms. Access all parameters via MIDI, tablet, or “modeless” front-panel operation for full control over granular processing.

The Particle 2 is performance friendly, with controls spaced for real-time tweaking and designed so you can explore new sonic territory while remaining in control. Use the assignable expression pedal or DIY-friendly remote switch for hands-free control. The Particle 2 is pedalboard-friendly with all jacks on top. With full MIDI control, stereo input/output, and +8 dBu maximum input level, it is also at home in modular setups or the studio.

FEATURES

3 pitch modes: detune, density, LFO

5 delay modes: random, density, LFO, random pitch, reverse

Modes can be combined for control over all grain parameters

Adjustable grain size and density

Pitch shift +/- 1 octave

Delay 0-2.5 seconds

Feedback with adjustable lowpass filter

Auto-freeze/stutter with adjustable threshold

Tap tempo/momentary freeze footswitch

Independent tap divisions for delay time, grain size, grain density, and LFO

Soft touch bypass (momentary or latching), user replaceable

Stereo input/output (TRS)

Assignable expression pedal, remote switch, remote tap, or MIDI port

Additional parameters via MIDI (USB or TRS)

MIDI clock synchronization

Presets (4 on front, 127 via MIDI)

Web-based editor for editing presets and accessing hidden parameters

TouchOSC template for iOS and Android

SPECIFICATIONS

Pedal Type: Delay, Pitch Shift

Analog/Digital: Digital

Presets: 4 x User (127 via MIDI)

Effects: 5 x Delay Modes, 3 x Pitch Modes

Max Delay Time: 2500ms

Tap Tempo: Yes

Inputs: 1 x 1/4" TRS

Outputs: 1 x 1/4" TRS

MIDI I/O: In/USB

Other I/O: 1 x 1/4" TRS (expression, control voltage, tap tempo, MIDI in, remote switch)

USB: 1 x Mini-B

Bypass Switching: Analog Buffered, DSP, Kill Dry

Software: Red Panda Web Editor

Power Source: 9V DC power supply (sold separately)

Power Usage: 250mA

Height: 2.5"

Width: 3.05"

Depth: 4.75"

Weight: 0.88 lbs.

Manufacturer Part Number: RPL-101V2
